Module 40 cm Module 80 cm

Produit ajouté au comparateur

Module 80 cm

R70/80PCE/T

1.638 €

Request offer View product Compare product

Features

  • Flue Removable gas exhaust flue grill made of cast iron
  • Knobs Made of aluminum with IPX5 water protection
  • Working top Made of AISI 304 stainless steel with a thickness of 20/10 mm

Constructive Data

  • Net weight (kg) 40,3
  • Net volume (m3) 0,164
  • Gross weight (kg) 53,9
  • Gross volume (m3) 0,383
  • Total eletric power (kW) 10,4
  • Electric power 1 (kW) 2,6
  • Electric power 2 (kW) 2,6
  • Electric power 3 (kW) 2,6
  • Electric power 4 (kW) 2,6
  • Electric power (V) 380-415
  • Phases 3N
  • Ampere (A) 24
  • Frequency (Hz) 50-60
  • Cable section (mmq) 5G4
  • Dimension (mm) 800x730x280
  • Packing dimensions (mm) 880x856x509

R70/80PCE/A

2.054 €

Request offer View product Compare product

Features

  • Flue Removable gas exhaust flue grill made of cast iron
  • Knobs Made of aluminum with IPX5 water protection
  • Working top Made of AISI 304 stainless steel with a thickness of 20/10 mm
  • Inner corners 90° spokes. Optional H2 spoking

Constructive Data

  • Net weight (kg) 58
  • Net volume (m3) 0,508
  • Gross weight (kg) 71,6
  • Gross volume (m3) 0,835
  • Total eletric power (kW) 10,4
  • Electric power 1 (kW) 2,6
  • Electric power 2 (kW) 2,6
  • Electric power 3 (kW) 2,6
  • Electric power 4 (kW) 2,6
  • Electric power (V) 380-415
  • Phases 3N
  • Ampere (A) 24
  • Frequency (Hz) 50-60
  • Cable section (mmq) 5G4
  • Dimension (mm) 800x730x870
  • Packing dimensions (mm) 880x856x1109

R70/80PCE/P

2.501 €

Request offer View product Compare product

Features

  • Flue Removable gas exhaust flue grill made of cast iron
  • Knobs Made of aluminum with IPX5 water protection
  • Handles The brushed aluminum handles allow for a secure and sturdy grip with a ergonomic lines
  • Working top Made of AISI 304 stainless steel with a thickness of 20/10 mm
  • Inner corners 90° spokes. Optional H2 spoking

Constructive Data

  • Net weight (kg) 64
  • Net volume (m3) 0,508
  • Gross weight (kg) 77,6
  • Gross volume (m3) 0,835
  • Total eletric power (kW) 10,4
  • Electric power 1 (kW) 2,6
  • Electric power 2 (kW) 2,6
  • Electric power 3 (kW) 2,6
  • Electric power 4 (kW) 2,6
  • Electric power (V) 380-415
  • Phases 3N
  • Ampere (A) 24
  • Frequency (Hz) 50-60
  • Cable section (mmq) 5G4
  • Dimension (mm) 800x730x870
  • Packing dimensions (mm) 880x856x1109

R70/80PCEQ/T

2.797 €

Request offer View product Compare product

Features

  • Flue Removable gas exhaust flue grill made of cast iron
  • Knobs Made of aluminum with IPX5 water protection
  • Working top Made of AISI 304 stainless steel with a thickness of 20/10 mm

Constructive Data

  • Net weight (kg) 40,3
  • Net volume (m3) 0,164
  • Gross weight (kg) 53,9
  • Gross volume (m3) 0,383
  • Total eletric power (kW) 10,4
  • Electric power 1 (kW) 2,6
  • Electric power 2 (kW) 2,6
  • Electric power 3 (kW) 2,6
  • Electric power 4 (kW) 2,6
  • Electric power (V) 380-415
  • Phases 3N
  • Ampere (A) 24
  • Frequency (Hz) 50-60
  • Cable section (mmq) 5G4
  • Dimension (mm) 800x730x280
  • Packing dimensions (mm) 880x856x509

R70/80PCEQ/A

3.213 €

Request offer View product Compare product

Features

  • Flue Removable gas exhaust flue grill made of cast iron
  • Knobs Made of aluminum with IPX5 water protection
  • Working top Made of AISI 304 stainless steel with a thickness of 20/10 mm
  • Inner corners 90° spokes. Optional H2 spoking

Constructive Data

  • Net weight (kg) 58
  • Net volume (m3) 0,508
  • Gross weight (kg) 71,6
  • Gross volume (m3) 0,835
  • Total eletric power (kW) 10,4
  • Electric power 1 (kW) 2,6
  • Electric power 2 (kW) 2,6
  • Electric power 3 (kW) 2,6
  • Electric power 4 (kW) 2,6
  • Electric power (V) 380-415
  • Phases 3N
  • Ampere (A) 24
  • Frequency (Hz) 50-60
  • Cable section (mmq) 5G4
  • Dimension (mm) 800x730x870
  • Packing dimensions (mm) 880x856x1109

R70/80PCEQ/P

3.660 €

Request offer View product Compare product

Features

  • Flue Removable gas exhaust flue grill made of cast iron
  • Knobs Made of aluminum with IPX5 water protection
  • Handles The brushed aluminum handles allow for a secure and sturdy grip with a ergonomic lines
  • Working top Made of AISI 304 stainless steel with a thickness of 20/10 mm
  • Inner corners 90° spokes. Optional H2 spoking

Constructive Data

  • Net weight (kg) 64
  • Net volume (m3) 0,508
  • Gross weight (kg) 77,6
  • Gross volume (m3) 0,835
  • Total eletric power (kW) 10,4
  • Electric power 1 (kW) 2,6
  • Electric power 2 (kW) 2,6
  • Electric power 3 (kW) 2,6
  • Electric power 4 (kW) 2,6
  • Electric power (V) 380-415
  • Phases 3N
  • Ampere (A) 24
  • Frequency (Hz) 50-60
  • Cable section (mmq) 5G4
  • Dimension (mm) 800x730x870
  • Packing dimensions (mm) 880x856x1109

R70/80CFE

3.591 €

Request offer View product Compare product

Features

  • Flue Removable gas exhaust flue grill made of cast iron
  • Knobs Made of aluminum with IPX5 water protection
  • Working top Made of AISI 304 stainless steel with a thickness of 20/10 mm
  • Standard equipment 1 x GN 2/1 oven grid

Constructive Data

  • Net weight (kg) 97,4
  • Net volume (m3) 0,508
  • Gross weight (kg) 111
  • Gross volume (m3) 0,835
  • Total eletric power (kW) 16,4
  • Electric power 1 (kW) 2,6
  • Electric power 2 (kW) 2,6
  • Electric power 3 (kW) 2,6
  • Electric power 4 (kW) 2,6
  • Electric power (V) 380-415
  • Phases 3N
  • Ampere (A) 25,5
  • Frequency (Hz) 50-60
  • Cable section (mmq) 5G4
  • Oven power (kW) 6
  • Oven type Static oven
  • Oven dimensions (mm) 555x660x257
  • Oven temperature range (°C) 50 - 300
  • Dimension (mm) 800x730x870
  • Packing dimensions (mm) 880x856x1109

R70/80CFEQ

5.082 €

Request offer View product Compare product

Features

  • Flue Removable gas exhaust flue grill made of cast iron
  • Knobs Made of aluminum with IPX5 water protection
  • Handles The brushed aluminum handles allow for a secure and sturdy grip with a ergonomic lines
  • Working top Made of AISI 304 stainless steel with a thickness of 20/10 mm
  • Standard equipment 1 x GN 2/1 oven grid

Constructive Data

  • Net weight (kg) 97,4
  • Net volume (m3) 0,508
  • Gross weight (kg) 111
  • Gross volume (m3) 0,835
  • Total eletric power (kW) 16,4
  • Electric power 1 (kW) 2,6
  • Electric power 2 (kW) 2,6
  • Electric power 3 (kW) 2,6
  • Electric power 4 (kW) 2,6
  • Electric power (V) 380-415
  • Phases 3N
  • Ampere (A) 25,5
  • Frequency (Hz) 50-60
  • Cable section (mmq) 5G4
  • Oven power (kW) 6
  • Oven type Static oven
  • Oven dimensions (mm) 555x660x257
  • Oven temperature range (°C) 50-300
  • Dimension (mm) 800x730x870
  • Packing dimensions (mm) 880x856x1109
